JX Filtration Automatic Backwash Filter – Key Features

JX Filtration February 26, 2026 Automatic Backwash Filter

The JX Filtration automatic backwash filter is designed for reliable and continuous solid-liquid separation. It features a fully automated backwashing system that cleans the filter elements without interrupting the main flow, ensuring consistent operation even during the cleaning cycle.

This filter is ideal for removing impurities from water and other liquids, with minimal maintenance and operational effort required. Its robust construction allows it to perform effectively even under severe operating conditions, maintaining stable performance over long periods.

Key Technical Specifications (XF-F Series):

Flow Rate: 1 to 5,000 m³/h
Filtration Rating: 25 to 3,000 microns
Working Pressure: 0 to 10 bar
Valve Type: Motorized or Pneumatic
Design Standards: GB150, HG/T21637, ASME
Filter Element Material: SS304, SS316, or Hastelloy
Valve Material: CS, SS304/316, or Hastelloy
Seal Material: Buna-N, EPDM, or Fluoroelastomer

The XF-F series can be equipped with different quantities of filter elements within a single housing, maximizing the filtration area while minimizing pressure loss. This design ensures energy efficiency and stable filtration performance.

The filter body is typically designed in accordance with chemical pipeline filter and steel pressure vessel standards. It can also be adapted to meet other specific design requirements. In addition, special materials such as titanium or pure nickel are available upon request to suit unique application needs.
